PROGRESS SYSTEM OF MANILLAR (PHDS)
close

The PHDS (Progressive Handlebar Damping System) is a handlebar mount designed for riders looking to reduce the transmission of impacts and vibrations to the hands during off-road riding. It is fitted in place of the original mount and proves especially useful on hard or rocky terrain, where sharp impacts are felt in the wrists and elbows.

It is machined from aluminium with a silver anodized finish, giving it corrosion resistance and a race-derived look. The part integrates rubber inserts within the mount itself, which absorb both vertical impacts and horizontal vibrations coming from the engine and chassis, without losing precision in handlebar control.

The photo shows a silver anodized aluminium block, with machined towers and black rubber inserts visible between the handlebar support surfaces, along with the mounting holes for the bolts.

In use, it filters out strong impacts before they reach the wrists and the joints of the humerus, dampens the continuous vibrations from the engine and chassis, and adds extra horizontal damping travel, giving a smoother handlebar feel without compromising riding precision.

A46001939500

Data sheet

Color
plata
APPROVALS
CCCUO_EU
MATERIAL
Aluminio
SUPERFICIE
Anodizada

Compatibility (51 models)

  • 125 SX 2023-2027
  • 125 XC 2023-2025
  • 125 XC-W 2025-2027
  • 150 EXC 2024-2025
  • 150 SX 2025
  • 250 EXC 2024-2025
  • 250 EXC-F 2024-2027
  • 250 EXC-F 6DAYS 2026-2027
  • 250 EXC-F Champion Edition 2025
  • 250 EXC-F Six Days 2024-2025
  • 250 EXC Champion Edition 2025
  • 250 EXC Six Days 2024-2025
  • 250 SX 2024-2027
  • 250 SX-F 2023-2027
  • 250 SX-F Adamo Edition 2025
New

Los productos disponibles se enviarán siempre que haya existencias. Aquellos que no estén disponibles de forma inmediata se solicitarán a nuestro proveedor oficial cada día laborable, momento en el que se calcularán los tiempos estimados de recepción, salvo durante el 24 de diciembre al 2 de enero, periodo en el que los pedidos se gestionarán a partir del 2 de enero debido a las vacaciones.

Los envíos se realizan mediante transportista, con un plazo aproximado de 48 a 72 horas laborables para entregas nacionales. Los envíos internacionales pueden tardar entre 5 y 10 días laborables, salvo en periodos de parón por mantenimiento, vacaciones o alta demanda, como durante el Black Friday.

La entrega de motos se coordina directamente con el comercial durante la compra.

KTM Progressive Handlebar Damping System (PHDS)

229.05
183.24 Save 20%

¡BLACK FRIDAY!

A46001939500
  • Machined handlebar anchor with cushion rubber inserts
  • Protects the wrists and joints of the humerus
  • Shock cushioning
  • Absorption of vibrations of the cycle and motor part
  • Additional horizontal cushioning of the handlebar
  • Precise handlebar control
  • There are three types of rubber inserts—green/soft SXS05125203, yellow/medium SXS05125204, and red/hard SXS05125205—which are sold separately.

FOR:

  • 125/250/350/450 SX/SX-F - 2023 forward
  • 250/300/350/450 EXC/EXC-F 2024 forward
